Gear cutting centre ID 101420

Name: Gear cutting centre ID 101420
SKU: 101420

0 EUR

bookmark Write a note

Print page

General information

Creation date 14.04.2025
Ad-ID 101420

Search criteria

Traverse X-axis 800 mm
Machine manufacturer (list selection) nomen nominandum

further specifications

Tip circle diameter max. 350 mm
Module range profile grinding 0,5 - 8 mm
Module range gear grinding 0,5 - 10 mm
Gear width max. 320 mm
Bevel angle max. +/-45 °

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

For hard fine machining

Workpiece length max. 800 mm, tip circle diameter max. 350 mm

With different tool and process technologies, you can realise application-specific, optimum solutions:

The counter-bearing tool spindle allows the use of dressable and non-dressable grinding worms or profile grinding wheels. By using attachment spindles, profile grinding wheels with a minimum diameter of 25 mm can also be used.

The machine can be loaded manually or automatically. The use of a machine-integrated ring loader enables short loading times for both bore parts and shaft-shaped workpieces.
