Vertical machining centre ID 101454
- Erstellungsdatum:
General information
| 17.04.2025 |
| 101454 |
Search criteria
| 5 Piece |
| 800 mm |
| 600 mm |
| 500 mm |
| 120 kg |
|
|
| 15 Piece |
|
| upon request |
further specifications
| 61-61-61 m/min |
| 1360 mm |
| 2330 mm |
| 3281 mm |
| 9,9 t |
Contact us
Report ad
Description
Table load max. 120 kg, X-Y-Z-axis rapid linear traverses max. 61 m/min, tool magazine places HSK-E40 18/36/68/168, HSK-E50 15/30/60/120/170/220, swivelling axis +30° / -110
Two-in-one solution for milling and grinding
The 5-axis CNC machining centre is able to combine milling and jig grinding on the same machine. The grinding setup in the machine has been designed in such a way that the workpiece dimensions and clamping surface remain constant even during automation. Nevertheless, the laser measuring system and the dressing spindle are positioned closer to the work area to enable a fast grinding process.
Advantages
- No influence on the workpiece dimensions
- No impairment of the clamping surface
- Fast commissioning of the sanding process
