Vertical machining centre ID 101453

Name: Vertical machining centre ID 101453
SKU: 101453

0 EUR

bookmark Write a note

Print page

General information

Creation date 17.04.2025
Ad-ID 101453

Search criteria

Number of NC-axis 5 Piece
Traverse X-axis 600 mm
Traverse Y-axis 600 mm
Traverse Z-axis 500 mm
Workpiece weight max. 500 kg
Workpiece width max. 900 mm
Main spindle speed max. 36000 rpm 42000 rpm
Tool interface [type] HSK-E40 HSK-E50
Tool stock min. (standard) [items] 15 Piece
Control (manufacturer) Heidenhain TNC 640
Machine manufacturer (list selection) upon request

further specifications

X-Y-Z-axis rapid linear traverse max. 61-61-61 m/min
Installation length 1360 mm
Installation width 2330 mm
Installation height 3281 mm
Machine weight 9,9 t

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

Table load max. 500 kg, X-Y-Z-axis rapid linear traverses max. 61 m/min, tool magazine places HSK-E40 18/36/68/168, HSK-E50 15/30/60/120/170/220

Two-in-one solution for milling and grinding

The 5-axis CNC machining centre is able to combine milling and jig grinding on the same machine. The grinding setup in the machine has been designed in such a way that the workpiece dimensions and clamping surface remain constant even during automation. Nevertheless, the laser measuring system and the dressing spindle are positioned closer to the work area to enable a fast grinding process.

Advantages

No influence on the workpiece dimensions
No impairment of the clamping surface
Fast commissioning of the sanding process
