Vertical machining centre ID 101409
- Erstellungsdatum:
General information
| 11.04.2025 |
| 101409 |
Search criteria
| 5 Piece |
| 900 mm |
| 850 mm |
| 700 mm |
| 1000 kg |
| 850 mm |
| 750 mm |
| 900 mm |
|
|
| 80 Piece |
|
| upon request |
further specifications
| 40-40-40 m/min |
| 9,7 s |
| 75 mm |
| 330 mm |
| 3893 mm |
| 3384 mm |
| 3062 mm |
| 11 t |
Contact us
Report ad
Description
Main spindle Torque max. 217 Nm, Power 22 kW, Speed 15,000 rpm, Tool stock min. 80
5-axis CNC machining centre with turning/swivelling table
The turning and swivelling table with bearings on both sides and the special travelling column concept guarantee the stability of the machine. With traverse y-axis of 900 x 850 x 700 mm (X/Y/Z), a clamping area of Ø 850 x 750 mm and a permissible clamping weight of 1,000 kg, the vertical machining centre is also designed for machining large and heavy parts, especially in tool and mould making.
Overview
- Large traverse y-axis of 900 x 850 x 700 mm (x/y/z)
- Turning and swivelling table mounted on both sides for high-precision machining performance
- 80-position tool magazine can be operated from the front
- Complete enclosure of the work area for a clean working environment
- Clamping surface moved to the front for improved accessibility
- Low overall height, low overall depth
- 5-axis simultaneous milling optional
