Vertical machining centre ID 101399
0 EUR
General information
| 11.04.2025 |
| 101399 |
Search criteria
| 5 Piece |
| 500 mm |
| 550 mm |
| 550 mm |
| 300 kg |
| 500 mm |
| 430 mm |
| 550 mm |
|
|
| 55 Piece |
|
| nomen nominandum |
further specifications
| 40-40-40 m/min |
| 9 s |
| 125 mm |
| 300 mm |
|
|
| 3244 mm |
| 2383 mm |
| 2400 mm |
| 5,5 t |
Contact us
Report ad
Description
Main spindle Torque max. 183 Nm, Power 29 kW, Speed 14,000 rpm
5-axis CNC machining centre with turning/swivel table supported on both sides
This vertical machining centre offers more precision on a smaller footprint. Particularly noteworthy is the standard equipment of the C-axis of the turning/tilt table with a liquid-cooled torque direct drive for fast and backlash-free positioning. The constantly guided Y-axis in conjunction with the solidly ribbed feed slides made of grey cast iron also reduces vibrations and guarantees a high surface quality.
Overview
- Traverse z-axis of 550 mm
- Turning swivelling table supported on both sides for high-precision machining
- Backlash-free direct drive in the C-axis
- 55- or 80-position tool magazine can be operated from the front
- Optimised chip fall thanks to vertical stainless steel cover
- Chip conveyor can be pulled out to the front on rollers to save space
- Low overall height, low overall depth
- 5-axis simultaneous milling optional
