Vertical machining centre ID 101390

Name: Vertical machining centre ID 101390
SKU: 101390

0 EUR

bookmark Write a note

Print page

General information

Creation date 08.04.2025
Ad-ID 101390

Number of NC-axis 5 Piece
Traverse X-axis 3200 mm
Traverse Y-axis 2450 mm
Traverse Z-axis 1100 mm
Workpiece weight max. 14000 kg
Main spindle speed max. 12000 rpm
Tool interface [type] HSK-A100
Tool stock min. (standard) [items] 40 Piece
Control (manufacturer) Hurco Max 5
Machine manufacturer (list selection) nomen nominandum

X-Y-Z-axis rapid linear traverse max. 15-15-10 m/min
Tool diameter max. 240 mm
Tool length max. 300 mm
Tool weight max. 30 kg
Main spindle power max. (100% c.d.f.) 53.0 kW
Main spindle torque max. (100% c.d.f.) 253 Nm
Installation length 10382 mm
Installation width 7165 mm
Installation height 6263 mm
Machine weight 43,8 t

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

5 NC axes, traverse X-Y-axis 3200-2450-1100 mm, workpiece weight max. 14000 kg

3-metre gantry machining centre

The good accessibility of the machining centre and the large traverse X-, Y- and Z-axes allow the machining of large and heavy components
High rigidity of the X, Y and Z axes for maximum stability
Powerful spindles allow the use of state-of-the-art tool technology
Solid cast iron machine frame
