Vertical machining centre ID 101389

Name: Vertical machining centre ID 101389
SKU: 101389

Bookmark Write a note

Print page

General information

Creation date 08.04.2025
Ad-ID 101389

Number of NC-axis 5 Piece
Traverse X-axis 3200 mm
Traverse Y-axis 2100 mm
Traverse Z-axis 900 mm
Workpiece weight max. 11000 kg
Main spindle speed max. 18000 rpm
Tool interface [type] HSK-A63
Tool stock min. (standard) [items] 40 Piece
Control (manufacturer) Hurco Max 5
Machine manufacturer (list selection) upon request

X-Y-Z-axis rapid linear traverse max. 15-15-10 m/min
Tool diameter max. 76 mm
Tool length max. 300 mm
Tool weight max. 7 kg
Installation length 9982 mm
Installation width 6815 mm
Installation height 5250 mm
Machine weight 37,7 t

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

5 NC axes, traverse X-Y-axis 3200-2100-900 mm, workpiece weight max. 11000 kg

3-metre gantry machining centre

The good accessibility of the machining centre and the large traverse X-, Y- and Z-axes allow the machining of large and heavy components
High rigidity of the X, Y and Z axes for maximum stability
Powerful spindles allow the use of state-of-the-art tool technology
Solid cast iron machine frame
