Vertical machining centre ID 101387

Name: Vertical machining centre ID 101387
SKU: 101387

0 EUR

bookmark Write a note

Print page

General information

Creation date 08.04.2025
Ad-ID 101387

Number of NC-axis 3 Piece
Traverse X-axis 3200 mm
Traverse Y-axis 2100 mm
Traverse Z-axis 920 mm
Workpiece weight max. 11000 kg
Main spindle speed max. 6000 rpm 10000 rpm
Tool interface [type] SK50
Tool stock min. (standard) [items] 40 Piece
Control (manufacturer) Hurco Max 5
Machine manufacturer (list selection) nomen nominandum

X-Y-Z-axis rapid linear traverse max. 15-15-10 m/min
Tool diameter max. 125 mm
Tool length max. 300 mm
Tool weight max. 15 kg
Main spindle power max. (100% c.d.f.) 48.0 kW
Main spindle torque max. (100% c.d.f.) 275 Nm 458 Nm
Installation length 9960 mm
Installation width 6360 mm
Installation height 4724 mm
Machine weight 35 t

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

X-Y-Z traverse X-axis 3200-2100-920 mm, workpiece weight max. 11000 kg

3-metre gantry machining centre

The good accessibility of the machining centre and the large traverse X-, Y- and Z-axes allow the machining of large and heavy components
High rigidity of the X, Y and Z axes for maximum stability
Powerful spindles allow the use of state-of-the-art tool technology
Solid cast iron machine frame
