Vertical machining centre ID 101386

Name: Vertical machining centre ID 101386
SKU: 101386

0 EUR

bookmark Write a note

Print page

General information

Creation date 08.04.2025
Ad-ID 101386

Number of NC-axis 3 Piece
Traverse X-axis 2200 mm
Traverse Y-axis 1700 mm
Traverse Z-axis 750 mm
Workpiece weight max. 8000 kg
Main spindle speed max. 6000 rpm 8000 rpm 10000 rpm 12000 rpm 15000 rpm
Tool interface [type] SK40 SK50
Tool stock min. (standard) [items] 40 Piece
Control (manufacturer) Hurco Max 5
Machine manufacturer (list selection) nomen nominandum

X-Y-Z-axis rapid linear traverse max. 32-32-24 m/min
Tool diameter max. 125 mm
Tool length max. 300 mm
Tool weight max. 15 kg
Main spindle power max. (100% c.d.f.) 18.0 kW 26.0 kW
Main spindle torque max. (100% c.d.f.) 189 Nm 237 Nm 284 Nm 408 Nm 544 Nm
Installation length 6432 mm
Installation width 7246 mm
Installation height 3899 mm
Machine weight 21 t

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Traverse X-Y-axis 2200-1700-750 mm, workpiece weight max. 8000 kg

2-metre gantry machining centre

The good accessibility of the machining centre and the large traverse X-, Y- and Z-axes allow the machining of large and heavy components
High rigidity of the X, Y and Z axes for maximum stability
Powerful spindles allow the use of state-of-the-art tool technology
Solid cast iron machine frame
