Vertical machining centre ID 101385

Name: Vertical machining centre ID 101385
SKU: 101385

0 EUR

bookmark Write a note

Print page

General information

Creation date 08.04.2025
Ad-ID 101385

Number of NC-axis 5 Piece
Traverse X-axis 950 mm
Traverse Y-axis 550 mm
Traverse Z-axis 500 mm
Workpiece weight max. 250 kg
Main spindle speed max. 18000 rpm
Tool interface [type] HSK-A63
Tool stock min. (standard) [items] 30 Piece
Control (manufacturer) Hurco Max 5
Machine manufacturer (list selection) nomen nominandum

X-Y-Z-axis rapid linear traverse max. 36-36-36 m/min
Tool diameter max. 76 mm
Tool length max. 300 mm
Tool weight max. 7 kg
Main spindle power max. (100% c.d.f.) 35.0 kW
Main spindle torque max. (100% c.d.f.) 119 Nm
Installation length 4187 mm
Installation width 3705 mm
Installation height 2885 mm
Machine weight 9,4 t

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

5 NC axes, traverse X-Y-axis 950-550-500 mm, workpiece weight max. 250 kg

5-axis CNC machining centre in portal design with turning/tilting table
