Vertical machining centre ID 101384

Traverse X-Y-axis 1600-1300-700 mm, workpiece weight max. 6000 kg

The CNC 3-axis machining centre combines stability with high precision and high surface quality. The powerful gantry machining centre is the perfect choice for anyone looking for a space-saving machine tool for particularly precise components. The stable and rigid gantry design is characterised by its temperature resistance, which enables high accuracy in CNC machining.

It is a high-speed machining centre, and machining is fast and efficient - a great advantage if you want to produce workpieces in large quantities. The standard scope of the machine includes generously dimensioned linear guides in all axes (X-, Y- and Z-axis) as well as a direct measuring system for x-, y- and z-displacement, which ensures the long-term accuracy of the machining centre. Reliable precision is ensured by the standard spindle cooler, an oil separator and a chip flushing system. The machine is equipped with automatic centralised lubrication for uncomplicated maintenance. CNC machining is supported by a control system that takes you from design to finished CNC workpiece particularly quickly thanks to intuitive dialogue programming.

The machining centre offers:

• Production of high-precision workpieces (e.g. in tool and mould making)
• High rigidity and stability of the linear guides in the X-axis, Y-axis and Z-axis
• Patented control system with time-saving dialogue programming for greater productivity
• Stable and rigid portal design with high temperature resistance
• Powerful spindle with HSK63A tool interface, speeds of up to 20,000 rpm and max. 35 kW spindle power
• Side-mounted, electrically driven tool changer with double gripper

Additional options for your CNC machine

The CNC milling machine can be equipped with optional accessories to optimally adapt the vertical machining centre to the requirements of your CNC production. These include, for example, a Renishaw measuring system for the workpieces or tools. Additional software functions can also be integrated into the control system. With the manufacturer's own Control and patented UltiMotion technology, for example, you can reduce your cycle times by up to 30% while simultaneously improving surface quality thanks to UltiMotion.
