Vertical machining centre ID 101383

Name: Vertical machining centre ID 101383
SKU: 101383

0 EUR

bookmark Write a note

Print page

General information

Creation date 01.04.2025
Ad-ID 101383

Number of NC-axis 3 Piece
Traverse X-axis 1350 mm
Traverse Y-axis 950 mm
Traverse Z-axis 600 mm
Workpiece weight max. 2500 kg
Main spindle speed max. 10000 rpm
Tool interface [type] SK50
Tool stock min. (standard) [items] 40 Piece
Control (manufacturer) Hurco Max 5
Machine manufacturer (list selection) nomen nominandum

X-Y-Z-axis rapid linear traverse max. 36-36-36 m/min
Tool diameter max. 125 mm
Tool length max. 300 mm
Tool weight max. 15 kg
Main spindle power max. (100% c.d.f.) 26.0 kW
Main spindle torque max. (100% c.d.f.) 336 Nm
Installation length 4640 mm
Installation width 5244 mm
Installation height 3561 mm
Machine weight 13 t

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Traverse X-Y-axis 1350-950-600 mm, workpiece weight max. 2500 kg

Highly stable gantry machining centre for fast and very precise production of large and heavy workpieces with high surface quality requirements.
