Cylindrical grinding machine ID 101414

Grinding head universal / diagonal, table / slide Z-axis 1800 mm, cross slide X-axis 370 mm, workpiece headstock mounting cone MK5, tailstock mounting cone MK4

Hardware specialities

• Engine power: Engine power S1 = 11.5 kW and S6 = 15.5 kW.
• Automation: various automation solutions for any components
• Z2 axis: for faster set-up of workpieces between centres (also in relation to fully automated machines)

Modular sanding head with high-precision B-axis

• 10 compact grinding head variants for optimised machine design in relation to the parts to be machined.
• Diagonal arrangement and new collision-free universal design with 500 mm disk diameter.

Workpiece headstock and tailstock

• Standard version with 100 kg workpiece weight
• Reinforced version with max. 200 kg
• High-torque for non-circular grinding
• Synchronised tailstock including automatic fine adjustment for productive applications

New technical highlights

• Capacity for workpiece weights up to 200 kg (centre height up to 250 mm)
• XL version for workpieces up to 1700 mm in length

Proven concept successfully built over 350 times

• Fanuc Control with 19'' touch screen
• Stable temperature thanks to integrated cooling circuit
• Innovative compact sanding head with 10 variants and 11.5 kW (max. 15.5 kW) Engine power (direct drive)
• Collision-free sanding arrangement of 3 tool positions and one measuring position on the sanding head
• Measuring probe arrangement without swivelling mechanism for increased measuring accuracy
• High form accuracy during non-circular grinding thanks to direct drive on the workpiece
• Replacement of belt-driven internal grinding spindles with cost-effective motorised spindles
• Large holding capacity with 200 mm or 250 mm centre height and up to 200 kg workpiece weight
• Dressing concept with optimised, generous stroke ratios
• Open system for automation, automatic door drive
• Integrated lifting system for grinding wheel change and tailstock assembly
• Service-friendly machine design

Base

• FEM-optimised cast bed
• Optimised sliding guide on Z-axis
• Linear guide on X-axis
