Cylindrical grinding machine ID 101413
- Erstellungsdatum:
General information
| 14.04.2025 |
| 101413 |
Search criteria
| 1000 mm |
| 500 mm |
| 150 kg |
| 200 mm |
| 500 mm |
| 100 mm |
| 150 mm |
|
| upon request |
further specifications
| 280 ° |
| 2700 mm |
| 2200 mm |
| 4 t |
Contact us
Report ad
Description
Grinding head universal / diagonal, table / slide Z-axis 1150 mm, cross slide X-axis 370 mm, workpiece headstock mounting cone MK5, tailstock mounting cone MK4
Grinding head
The modular sanding head concept enables 10 different sanding head variants with up to 3 tool positions and one measuring head position. Each individual position is arranged to ensure maximum freedom from collision. In conjunction with the large centre distances, this ensures optimum flexibility when machining different component sizes.
Universal workhead
- Applications with stationary or rotating spindle 1-1,000 rpm
- Roundness accuracy ≤ 0.4 μm (optionally ≤ 0.2 μm)
- Integrated fine angle adjustment with correction range ± 1.5'
Workhead with direct drive and C-axis
- For high-precision non-circular grinding
- n 1-1,000 rpm
- Roundness accuracy < 0.4 μm
- Lower part with fine angle adjustment with correction range ± 1.5'
Tailstock 100
Up to 100 kg workpiece weight
Morse taper 4
Stroke 49 mm
Adjustment range ± 30 μm
Pneumatic lift-off
Tailstock 150
- Up to 150 kg workpiece weight
- Up to 200 kg workpiece weight with reinforced tailstock
- Morse taper 4
- Stroke 49 mm
- Adjustment range ± 75 μm
- Pneumatic lift-off
Synchronised tailstock
- Machining of shaft parts without driver
- Quill with MK4 and stroke 49 mm
- Adjustment range ± 75 μm
- Automatic cylinder correction (optional)
