Cylindrical grinding machine ID 101412
- Erstellungsdatum:
General information
| 14.04.2025 |
| 101412 |
Search criteria
| 1000 mm |
| 400 mm |
| 100 kg |
| 200 mm |
| 500 mm |
| 80 mm |
| 150 mm |
|
| upon request |
further specifications
| 240 ° |
| 3400 mm |
| 2200 mm |
| 4,1 t |
Contact us
Report ad
Description
Sanding head universal / diagonal, table / slide Z-axis 1150 mm, cross slide X-axis 365 mm, workpiece headstock mounting cone MK5, tailstock mounting cone MK4
An all-rounder for various sanding applications
This universal cylindrical grinding machine is a cost- and cycle time-optimised, energy-efficient standard machine with a very good price-performance ratio. The machine is characterised by high availability, process safety, reliability, productivity and flexibility, as well as easy retooling.
Other features include the automatic 1° indexing axis with high positioning accuracy, the sanding head for two external sanding discs with ø 500 mm (as main and secondary disc) and the direct-drive internal sanding spindles up to 60,000 rpm. The machine can be retrofitted in a variety of ways, including with a tailstock, active longitudinal positioning, gating and balancing sensors and extended dressing options.
Features and options
- Unrivalled price-performance ratio
- BLUE Solution software on a 19″ touchscreen
- Guided programming and retooling, even for inexperienced operators
- The standard machine for beginners and experts in precision grinding
- Designed for workpieces smaller than Ø 400 mm x 1000 mm
- Between centres up to 100 kg, overhung up to 80 kg
