Multi-spindle machining centre 101251
- Erstellungsdatum:
General information
| 18.12.2024 |
| 101251 |
Search criteria
| 5 Piece |
| 2 Piece |
| 1450 mm |
| 1200 mm |
| 1035 mm |
| 1200 mm |
| 680 mm |
| 1200 mm |
|
|
| upon request |
further specifications
| 8-4-14 m/s2 |
| 80-50-100 m/min |
| 2,7 s |
| 5080 mm |
| 4750 mm |
| 3550 mm |
| 35 t |
Contact us
Report ad
Description
3 linear axes, 2 rotary axes, single disc and double disc magazine, table loading 2 x 750 kg, table diameter 512 mm
Machining centre for frame structure and chassis parts
The machine concept of this multispindle machining centre guarantees customers from the automotive industry flexible and precise 5-axis machining of frame structure and chassis parts as well as battery housings.
As a stand-alone machining centre or linked to other machines, the twin-spindle machining centre enables two workpieces to be machined in parallel in the shortest possible time - including high machine dynamics and ideal chip removal.
- Three linear and two rotary axes enable 5 to 6-sided machining.
- The X and Z linear axes move the machining spindle.
- Optimised temperature concept
- X and Z axes with maximum dynamics and rigidity
- Perfected for automated loading
Advantages
- Best chip fall
- High dynamics
- High production flexibility
- High machining accuracy
- Customised workpiece loading
- As a stand-alone machine or in combination
- Suitable for MQL machining
- Short chip-to-chip times
