Horizontal turning machine ID 101347
- Erstellungsdatum:
General information
| 26.03.2025 |
| 101347 |
Search criteria
| 1100 mm |
| 16000 mm |
| 1 Piece |
| 8 Piece |
| no |
| yes |
| yes |
| upon request |
further specifications
|
| 5400 mm |
| 4300 mm |
| 15,5 t |
Contact us
Report ad
Description
Turning diameter over bed / facing slide 1500 / 1100 mm, facing slide travel 750 mm, turning tool cross-section 50 x 50 mm, swing diameter 1500 mm
An automatically switching turret and a second chip guard door allow full CNC operation and thus the expansion of economical use for medium series as an alternative to the CNC turning machine.
Workpieces weighing up to 16 tonnes can be machined economically and precisely. The basis for this is the heavy, rigid box bed.
The guideways for bed slides (double prism guide plus 2 flat guides for additional support of the bed slide) as well as tailstocks and risers (prism and flat guide) are a proven combination of both guide concepts. Large guide surfaces with low surface pressure ensure high guide reliability as well as high continuous and repeat accuracy.
Special equipment
- Y-axis
- C-axis
- 4-cavity parat tool carrier on top support and drill stand
- 4-position universal turret
- 8-position disc turret
- Turning, drilling and milling equipment
- Drill stand with additional support stand for long boring bars
- 0-point clamping system for quick change of tool carriers
- Heavy-duty roller setting vice
- etc.
