Horizontal turning machine ID 101345
- Erstellungsdatum:
General information
| 26.03.2025 |
| 101345 |
Search criteria
| 810 mm |
| 20000 mm |
| 1 Piece |
| 8 Piece |
| no |
| yes |
| yes |
| upon request |
further specifications
|
| 4578 mm |
| 2656 mm |
| 8,6 t |
Contact us
Report ad
Description
Turning diameter over bed / facing slide 1110 / 810 mm, facing slide travel 540 mm, turning tool cross-section 40 x 25 mm, swing diameter 1110 mm
Workpieces of almost all lengths, diameters, weights and materials can be machined economically and precisely. The basis for this is the heavy, rigid box bed.
The above data refers to the CNC version of the horizontal turning machine. There is also a cycle-controlled version with a 4-cavity tool carrier instead of a turret.
Special equipment
- Y-axis
- C-axis
- 4-fold parat tool carrier on top support and drill stand
- 4-position universal turret
- 8-position disc turret
- Turning, drilling and milling equipment
- Drill stand with additional support stand for long boring bars
- 0-point clamping system for quick change of tool carriers
- Heavy-duty roller setting vice
- etc.
