Horizontal turning machine ID 101342
0 EUR
General information
| 26.03.2025 |
| 101342 |
Search criteria
| 435 mm |
| 8000 mm |
| 1 Piece |
| 8 Piece |
| nein |
| ja |
| ja |
| nomen nominandum |
further specifications
|
|
|
| 3830 mm |
| 2156 mm |
| 5 t |
Contact us
Report ad
Description
Turning diameter over bed / facing slide 640 / 435 mm, facing slide travel 345 mm, turning tool cross-section 32 x 25 mm, swing diameter 640 mm
The handwheels arranged according to the latest ergonomic principles and the control panel inclined towards the operator enable simple and safe operation of the universal turning machine and largely fatigue-free working.
The 2-stage gearbox is automatically shifted directly by programming or from the control panel at the touch of a button, with a corresponding display on the control screen.
Override potentiometer for spindle and feed optional.
The above data refers to the CNC version of the horizontal turning machine. There is also a cycle-controlled version with a 4-cavity tool carrier instead of a turret.
Optional equipment
- Y-axis
- C-axis
- 4-fold parat tool carrier on top support and drill stand
- 4-position universal turret
- 8-position disc turret
- Turning, drilling and milling equipment
- Drill stand with additional support stand for long boring bars
- 0-point clamping system for quick change of tool carriers
- Heavy-duty roller setting vice
- etc.
