Horizontal machining centre 101307

Erstellungsdatum:

Bookmark Write a note

Print page

General information

Creation date 06.03.2025
Ad-ID 101307

Search criteria

Number of NC-axis 3 Items
Traverse X-axis 800 mm
Traverse Y-axis 800 mm
Traverse Z-axis 800 mm
Workpiece weight max. 750 kg
Workpiece width max. 850 mm
Workpiece height max 1050 mm
Main spindle speed max. 12000 rpm
Tool interface [type] BT-50 HSK-A100 SK-50
Tool stock min. (standard) [items] 60 Piece
Control (manufacturer) Fanuc G-Tech 31 iB
Machine manufacturer (list selection) upon request

further specifications

X-Y-Z-axis rapid linear traverse max. 60-60-60 m/min
Tool diameter max. 320 mm
Tool length max. 500 mm
Tool weight max. 20 kg

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

Processes workpieces up to size D 850 x H 1,050 mm and a weight of 750 kg. Thanks to the BT/SK 50 tool interface, the cutting performance of this machine is comparable to that of the next largest model. It was developed for heavier cutting and carbide machining and processes hardened materials with ease.
