Hard turning machine ID 101391

Spindle bore 48 mm, Turning diameter 239 mm, bar capacity 42 mm

For the most demanding work

This hard turning machine is suitable for high-precision and high-performance turning and enables unrivalled part quality and production capacities. The machine tools in this series have been developed for two-axis high-precision machining or complex multi-tasking operations that require a high degree of precision and delicate part handling. Parts can also be completely machined in a single set-up.

The most common functions are pre-configured so you can select the appropriate machine tool configuration to produce your parts in the most effective and profitable way.

Features

• High machine rigidity qualified by FEA technology (Finite Element Analysis)
• High surface quality of 0.2 μ or better
• Circularity test for maximum geometric accuracy
• Dynamic balancing of spindle and drive motor
• Integrated wrap-around spindle motors without belts
• Matched high-precision spindle bearings
• Ability to maintain total diameter deviation within 3 μ after a short warm-up time
• High repeatability of the axes of 0.76 μ
• Robust control, motor and drive package with 0.1 μ control resolution
• High-precision digital linear glass scales

Control system and software

• Tool offset with geometry / wear (99) (XYZR)
• Inch / metric selection according to G-code
• Memory extension 64 Kbyte (160 metres)
• Absolute / incremental programming
• Alarm display
• Setting the automatic coordinate system
• Background processing
• Skip block
• Fixed cycle (turning / drilling)
• Chamfer / corner radius
• Circle interpolation through R programming
• Programming of constant cutting speed
• Continuous thread cutting
• Setting the coordinate system (G50)
• User-defined macro B
• Decimal point programming
• Diameter / radius programming
• Programming with direct drawing dimensioning
• Display position, programme, alarm history
• Ethernet capable
• Advanced part programme editing (copy / replace)
• External workpiece number search
  Flexible reference run
