Mill-turn centre ID 101380
0 EUR
General information
| 28.03.2025 |
| 101380 |
Search criteria
| 5 Items |
| 500 mm |
| 450 mm |
| 450 mm |
| 500 mm |
| 630 mm |
| 250 kg |
|
|
|
| nomen nominandum |
further specifications
| 30-30-30 m/min |
| 630 mm |
| 20 rpm |
| 8 s |
| 40 Items |
| 130 mm |
| 300 mm |
| 6 kg |
|
|
| 2215 mm |
| 2262 mm |
| 2219 mm |
| 4,4 t |
Contact us
Report ad
Description
An NC swivelling rotary table with direct path measuring system enables full 5-axis simultaneous machining.
Main spindle
- Integrated spindle motor
- Automatic tool clamping system
- External coolant supply via spray nozzles
- Internal coolant supply (optional)
- Hydraulic clamping system
- Grease lubrication
- Internal spindle cooling by means of fluids
- Hybrid bearing ⌀ 70 mm
- Minimum quantity lubrication (option)
Machining capacity steel:
- Milling 400 ccm/min
- Drilling ⌀ 30 mm
- Thread cutting M20
NC swivelling rotary table
- Swiveling range C-axis 360°
- B-axis swivelling range -5 to +100°
- Clamping surface ⌀ 630 x 500 mm
- Max. Loading weight: 250 kg
- Direct position measuring system (rotary encoder)
- Rotary feed-through for hydraulics and pneumatics
- High-precision roller bearings in both axes
options
- Spindle 10,000 min-¹
- Spindle 14,000 min-¹
- Spindle 20,000 min-¹
- Tool measuring probe Blum / Renishaw / Heidenhain
- Workpiece measurement Blum / Renishaw / Heidenhain
- Kinematics calibration set
- EKZ / IKZ Coolant systems 40 bar
- Paper band filter
- Double changeover filter
- Rotating inspection window
- Oil mist separator
- Machine roof
- Coolant/blown air changeover
- Electronic handwheel - wireless
- Automatic machine door
- Free M-codes
- 3D machine model
- SK40, BT40 tool interface
