Mill-turn centre ID 101378
0 EUR
General information
| 28.03.2025 |
| 101378 |
Search criteria
| 6 Items |
| 2200 mm |
| 1300 mm |
| 1200 mm |
| 1800 mm |
| 2000 kg |
|
|
|
| nomen nominandum |
further specifications
| 4 m/s2 |
| 50-50-50 m/min |
| 1800 mm |
| 300 rpm |
| 39 Items |
| 125 mm |
| 300 mm |
| 8 kg |
|
|
| 6780 mm |
| 6550 mm |
| 5150 mm |
| 36 t |
Contact us
Report ad
Description
X-Y-Z traverse X-axis 2200-1300-1200 mm, main spindle power max. 27 kW, torque 130 Nm
Highlights:
- 5-axis simultaneous machining
- Extended traverse y-axis: 1,050 mm
- Milling and turning in one clamping operation thanks to Hirth-clamped main spindle
- Heidenhain TNC 640 Control
- Tool magazine with 52 pockets
The universal 5-axis machining centre impresses with maximum rigidity and enables both the machining of high-strength materials and the processing of delicate component structures. As a mill-turn centre, the machine opens up a wide range of machining options at speeds of up to 800 rpm.
Swivelling milling head
- Swivelling range: -10° to +187°
- Direct drive by torque motor
- High acceleration rates
- Excellent positionability
Mill spindle
- Large selection of spindle variants for milling-turning machining
- Perfect power transmission to the turning tool thanks to Hirth clamping
- High-torque milling with up to 253 Nm torque (S6)
Rotary table
- Direct drive by torque motor
- Excellent acceleration values and high-precision positioning
- Speed of up to 800 rpm
- Integrated zero-point clamping system
