Mill-turn centre ID 101376
- Erstellungsdatum:
General information
| 28.03.2025 |
| 101376 |
Search criteria
| 5 Items |
| 1000 mm |
| 800 mm |
| 700 mm |
| 900 mm |
| 1000 kg |
|
|
|
| upon request |
further specifications
| 4 m/s2 |
| 40-40-40 m/min |
| 900 mm |
| 800 rpm |
| 52 Items |
| 300 mm |
| 8 kg |
| 5000 mm |
| 5800 mm |
| 3500 mm |
| 15 t |
Contact us
Report ad
Description
X-Y-Z traverse X-axis 1000-800-700 mm, main spindle power max. 27 kW, torque 130 Nm
Highlights:
- Highly dynamic 5-axis simultaneous machining
- Rotary table with torque drives ensures excellent acceleration
- Milling and turning in a single clamping operation thanks to Hirth-clamped main spindle
- Control Heidenhain TNC 640
- Tool magazine with 52 pockets
The universal 5-axis machining centre impresses with maximum rigidity and enables both the machining of high-strength materials and the processing of delicate component structures. As a mill-turn centre, the machine opens up a wide range of machining options at speeds of up to 800 rpm.
Swivelling milling head
- Swivelling range: -10° to +187°
- Direct drive by torque motor
- High acceleration rates
- Excellent positionability
Mill spindle
- Large selection of spindle variants for milling-turning machining
- Perfect power transmission to the turning tool thanks to Hirth clamping
- High-torque milling with up to 253 Nm torque (S6)
Rotary table
- Direct drive by torque motor
- Excellent acceleration values and high-precision positioning
- Speed of up to 800 rpm
- Integrated zero-point clamping system
