Mill-turn centre 101290

Name: Mill-turn centre 101290
SKU: 101290

0 EUR

bookmark Write a note

Print page

General information

Creation date 14.02.2025
Ad-ID 101290

Search criteria

Number of NC-axis 5 Items
Traverse X-axis 1700 mm
Traverse Y-axis 1500 mm
Traverse Z-axis 1150 mm
Workpiece height max 1665 mm
Workpiece diameter max. 1700 mm
Main spindle speed max. 10000 rpm
Control (manufacturer) Mazatrol Smooth Ai
Machine manufacturer (list selection) nomen nominandum

further specifications

X-Y-Z-axis rapid linear traverse max. 52 m/min
Table speed max. 500 rpm
Tool stock min. (standard) [items] 43 Items

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

Various milling spindle options are available: a standard spindle with 10,000 rpm, a high-speed spindle with 15,000 rpm and a high-torque spindle suitable for difficult-to-machine materials with 5,000 rpm.

The table is driven by a direct drive motor, ensuring exceptional turning performance. Versatile multi-function machining is made possible by the precise indexing of the B-axis and C-axis in 0.0001° increments. In addition, the compact, swivelling Mill spindle helps to minimise the risk of collisions.
