My note

Mill-turn centre 101288

Name: Mill-turn centre 101288
SKU: 101288

0 EUR

bookmark Write a note

Print page

General information

Creation date 14.02.2025
Ad-ID 101288

Search criteria

Number of NC-axis 5 Items
Traverse X-axis 1425 mm
Traverse Y-axis 1050 mm
Traverse Z-axis 1050 mm
Workpiece height max 1400 mm
Workpiece diameter max. 1250 mm
Main spindle speed max. 10000 rpm
Machine manufacturer (list selection) nomen nominandum

further specifications

X-Y-Z-axis rapid linear traverse max. 52 m/min
Table diameter 1250 mm
Table speed max. 550 rpm
Tool stock min. (standard) [items] 43 Items

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

The machine is equipped with a single table and offers a generous machining area of Ø1,250 mm × 1,400 mm and a maximum load capacity of 1,750 kg (including pallet weight).

Particularly noteworthy is the high productivity achieved through the effective integration of various machining processes and versatile functions such as 5-axis machining, high-speed machining and high-torque machining.

This multi-function machine is ideal for reliable and highly productive precision machining.
