Travelling column milling machine ID 101353

Name: Travelling column milling machine ID 101353
SKU: 101353

0 EUR

bookmark Write a note

Print page

General information

Creation date 26.03.2025
Ad-ID 101353

Search criteria

Number of NC-axis 5 Piece
Traverse X-axis 7500 mm
Traverse Y-axis 1000 mm
Traverse Z-axis 1000 mm
Workpiece weight max. 9000 kg
Workpiece height max 1000 mm
Collision circle 1300 mm
Main spindle speed max. 12500 rpm 20000 rpm
Tool interface [type] HSK-A100 HSK-A63 SK40 SK50
Tool stock min. (standard) [items] 60 Piece
Control (manufacturer) Heidenhain iTNC 640 Siemens S840D sl
Machine manufacturer (list selection) nomen nominandum

further specifications

X-Y-Z-axis acceleration max. 5 m/s2
X-Y-Z-axis rapid linear traverse max. 40-40-40 m/min
Tool diameter max. 160 mm
Tool length max. 400 mm
Tool weight max. 20 kg
Main spindle power max. (100% c.d.f.) 45.0 kW 54.0 kW
Main spindle torque max. (100% c.d.f.) 130 Nm 200 Nm
Installation length 138ßß mm
Installation width 5100 mm
Installation height 3600 mm
Machine weight 44 t

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

Table dimensions B x L 8000 x 1000 mm, table load max. 9000 kg, rotary table (C-axis) Speed max. 40 (rpm), rotary table (C-axis) torque max. 2700 Nm

Modular equipment variants are available for this travelling column machining centre, depending on the performance requirements. To guarantee customised power, the machine tools are equipped with the latest generation of Heidenhain iTNC640 controls as standard. Siemens 840D sl is available as an alternative.
