Travelling column milling machine for machining large parts ID 101348
- Erstellungsdatum:
General information
| 26.03.2025 |
| 101348 |
Search criteria
| 5 Piece |
| 5000 mm |
| 1500 mm |
| 1100 mm |
| 3000 kg |
| 1000 mm |
|
|
| 24 Piece |
| upon request |
further specifications
| 2 m/s2 |
| 35-35-35 m/min |
| 200 mm |
| 300 mm |
| 15 kg |
Contact us
Report ad
Description
Table speed (rpm) 20, torque with table clamped max. 5000 Nm, tool magazine and number of tools: disc magazine 24 / 30, horizontal disc magazine 40 / 60
This universal milling machine has a movable longitudinal column structure (with X-axis strokes of 3 to 5 metres) and a transverse movement by ram, which allows the machine to work in pendulum mode on two separate machining zones or to machine a single long part. Thanks to the various configuration options, the Frazer Box is suitable for subcontractors (general engineering and mould making) and guarantees extremely low hourly costs.
Features
- Fully enclosed work area, with guard integrated into the machine bed for effective chip and coolant evacuation
- Perfect symmetry thanks to the BOX in BOX system with linear guides on the machine ram
- Minimal foundation costs and maximum rigidity and compactness of the machine thanks to the one-piece substructure
- Rotary table integrated into the machine bed with rotary option available
- Multiple milling heads available for different machining requirements
