Turning Center ID 101366
0 EUR
General information
| 28.03.2025 |
| 101366 |
Search criteria
| 460 mm |
| 713 mm |
| 82 mm |
| 1 items |
| 15 items |
| 12 items |
| ja |
| ja |
| ja |
| nomen nominandum |
further specifications
|
|
|
|
|
|
|
|
|
| 2542 mm |
| 1760 mm |
| 2120 mm |
| 7,5 t |
Contact us
Report ad
Description
Main spindle Speed max. 4,000 (rpm), power max. 22 kW, torque max. 366 Nm, X-Y-Z-axis traverse 310-120-640 mm, B-axis traverse 640 mm, X-Y-Z-axis traverses max. 30-30-15 m/min, Rapid linear traverses max. 30 m/min, X-Y-Z-axis acceleration max. 9.8 m/s2, tailstock 640 m/min
Integrated spindles
The spindle is driven by a motor that is integrated into the headstock. This robust spindle design guarantees excellent damping properties and significantly improves concentricity and surface quality.
Turret with integral motor
This turning Center has a turret with an integral motor with 12,000 rpm, fully oil-cooled and with hydraulic clamping.
- 12-position turret disc for CMZ tool holders
- 15-position turret disc for N-55 tool holders
Automation
Thanks to the GL20 II gantry robot, the automation of small and large batches is possible in all models of the series. The manufacturer offers various workstockers with large storage options to extend autonomy times.
