Turning Center ID 101354
- Erstellungsdatum:
General information
| 27.03.2025 |
| 101354 |
Search criteria
| 120 mm |
| 600 mm |
| 38 mm |
| 2 items |
| 24 items |
| 12 items |
| yes |
| yes |
| yes |
|
| upon request |
further specifications
|
|
|
|
|
| 2445 mm |
| 2043 mm |
| 1934 mm |
| 6,6 t |
Contact us
Report ad
Description
Main spindle speed max. 6000 (rpm), Max. bar capacity 38 mm, max. turning lenght 600 mm, max. X-Y-Z-axis rapid linear traverse 18-30-18 m/min, max. X-Y-Z-axis acceleration 9.8 m/s2 (1G), tailstock travel 368 mm
The turning Center with Counter spindle and up to two turrets is designed for turning small parts (bar machining) and competes with sliding headstock automatic lathes. Its precision and reliability make it ideal for machining complex parts. This machine tool is the preferred choice for turning mass-produced parts. With significantly reduced cycle times, it is specially designed for large series production.
In this multi-turret turning machine, the 24-station turret with a large-dimensioned "Curvic Coupling" takes over the hydraulic locking, which gives it high stability and precision.
Tailstock (optional)
One of the options for this multi-turret machine is the optional tailstock, which is attached to the Counter spindle.
2 turrets, 3channels
The turning Center has two turrets, although the CNC has 3 channels, which allow 3 programs to be executed simultaneously with the corresponding correction. The counter spindle (axes X3 and Z3) can work in combination with both the upper and lower turrets on channel 3 of the CNC. This makes it possible to place two tools in the two turrets and machine with three tools simultaneously.
Advantages
- Direct drives (no belts)
- One or two oil-cooled turrets with driven tools
- Mobile Counter spindle, which can represent an additional X3 and Z3 movement of the turrets
- Synchronized turning of 2 tools
- Can support longer components with a tailstock above or below the Counter spindle
