Turn-mill centre ID 101492

Name: Turn-mill centre ID 101492
SKU: 101492

0 EUR

bookmark Write a note

Print page

General information

Creation date 25.04.2025
Ad-ID 101492

Search criteria

Workpiece diameter max. 520 mm
Workpiece length max. 4500 mm
Counter spindle? nein
Y-axis? ja
(Turn-)mill spindle? ja
Control (manufacturer) Siemens Sinumerik One
Machine manufacturer (list selection) upon request

further specifications

Traverse X-axis 800 mm
Traverse Y-axis 400 mm
Mill spindle speed max. 5000 rpm 8000 rpm 9000 rpm 12000 rpm
Mill spindle power max. 27.0 kW 35.0 kW
Mill spindle torque max. 175 Nm 233 Nm 263 Nm 420 Nm

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

Centre distance 4500 mm, mechatronic tailstock, O.D. of slide 520 mm, swivel angle B-axis 220°, disc tool magazine 50/100/150/200//36/72/108/144

The turning-drilling-milling centre belongs to a new generation of multifunctional machine tools for the complete machining of complex chuck and shaft parts with a turning diameter of up to 520 mm. In addition to superior power and torque values of the spindle drives, enormous feed forces on all axes ensure impressive dynamics and maximum productivity.

Highlights

Wide guide spacing for stable mounting of large steady rests
Pick-up magazine for long tools with standard tool interface
B-axis turning
4-axis turning
Workpiece transfer
High-precision measuring with integrated measuring probe
