Turn-mill centre 101294

Name: Turn-mill centre 101294
SKU: 101294

0 EUR

bookmark Write a note

Print page

General information

Creation date 21.02.2025
Ad-ID 101294

Search criteria

Workpiece diameter max. 500 mm
Workpiece length max. 500 mm
Chuck diameter 20 mm
Bar capacity max. 51 mm
(Turn-)mill spindle? ja
Counter spindle? nein
Y-axis? ja
Control (manufacturer) Mazartol SmoothG
Machine manufacturer (list selection) nomen nominandum

further specifications

Traverse X-axis 450 mm
Traverse Y-axis 200 mm
Traverse Z-axis 550 mm
Turn-mill spindle speed max. 12000 rpm
Tool stock turn-mill spindle min. (standard) [items] 20 Items
Main spindle speed max. 5000 rpm

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

This compact machine is specially designed for processing large workpieces. It offers a maximum machining diameter of Ø500 mm and a maximum machining length of 500 mm. Thanks to the generous traverse y-axis of 200 mm, various work processes such as face milling, end milling and drilling can be carried out in the extended machining area without the need to index the C-axis.
