DMG MORI NHX 4000 4th generation

Bookmark Write a note

Print page

General information

Creation date 13.02.2025
Ad-ID 101282

Number of NC-axis 4 Items
Traverse X-axis 560 mm
Traverse Y-axis 560 mm
Traverse Z-axis 660 mm
Workpiece weight max. 400 kg
Main spindle speed max. 15000 rpm 20000 rpm 30000 rpm
Tool interface [type] BT40 CAT40 HSK-A63
Control (manufacturer) Fanuc F31iB Siemens S840D sl
Machine manufacturer (list selection) DMG MORI Aktiengesellschaft

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Highlights

Dynamic

Up to 70,000 mm/min feed drive and up to 1.2 g acceleration
New high-speed speedMASTER spindle with 20,000 rpm and 400 V as standard
Servo Sense for the workpiece (Z/B-axis) to optimize table acceleration/deceleration

Maximum rigidity

Thick, highly rigid bed with 3-point support
Highly rigid bed thanks to stepped guide rails on the X-axis
Optimized basic structure through the use of analysis technology early in the design phase

Unique solutions to problems with chips, coolant, and mist

Optimal automation potential

Optionally equipped with hydraulic/pneumatic connection points required for automation
Tool Visualizer for automation and quantification of tool measurement optionally available
Compatible not only with pallet handling, but also with tool handling and robot systems
