DMG MORI LASERTEC 30 SLM 3rd generation

Bookmark Write a note

Print page

General information

Creation date 21.11.2024
Ad-ID 101234

Maximum part length 325 mm
Maximum part width 325 mm
Maximum part height 400 mm
Minimum layer thickness 30 µm
Maximum layer thickness 90 µm
Machine manufacturer (list selection) DMG MORI Aktiengesellschaft

Minimum beam focus diameter 80 µm
Maximum beam focus diameter 80 µm

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Highlights

Additive manufacturing using selective laser melting (SLM) in a powder bed

Highly complex components with integrated functions
Internal, contour-close cooling channels
Weight reduction through topology optimization, lattice and honeycomb structures
Simultaneous development of different designs
Shortened product development times through immediately available prototypes made from series production materials

100% machine tool design for SLM technology

Build volume: 325 x 325 x 400 mm
Single, dual, or quad lasering with high-precision optical modules and complete overlap of the scan fields
Interchangeable build container for reduced job-to-job times
Bi-directional coater with collision protection system
CELOS X with easyAM—detailed work instructions for simplified machine operation and maintenance

New benchmark for robustness and repeatability

rePLUG – The powder module for fast material changes

Automated powder handling: Integrated powder recycling for maximum efficiency and maximum occupational safety thanks to a closed material cycle
One material per rePLUG – Unlimited expansion of the material range thanks to a modular exchange system and contamination-free material changes
Integrated sieving and powder drying function under protective gas atmosphere
Industrialized powder filling and precise weight detection in the main tank
Optional: rePLUG FLEX – The additional powder module, specially developed for material and process parameter development on the series production line.
