External cylindrical grinding machine ID 101442
- Erstellungsdatum:
General information
| 16.04.2025 |
| 101442 |
Search criteria
| 400 mm |
| 350 mm |
| 150 kg |
| 175 mm |
| 600 mm |
| 120 mm |
| no |
|
| upon request |
further specifications
| 2400 mm |
| 2900 mm |
| 6,3 t |
Contact us
Report ad
Description
External grinding length max. 400 mm, Rapid linear traverses Z-axis max. 15 m/min, Rapid linear traverses X-axis max. 7.5 m/min, Table / slide Z-axis travel 600 mm, Cross slide X-axis travel 350 mm
The modular external cylindrical grinding machine was developed for medium and large series. The machine tool is characterised by hydrostatic guides and a wide range of applications. It offers synchronous machining, prism and bar grinding as well as the integration of additional operations. Automation solutions range from small integrated handling to complex systems with autonomous cells.
Features & options
Axis configuration: Range +6° to -30° configurable
Burrless grinding: Manufacturer of sharper, burr-free edges
Prismatic sanding system:
- Very efficient production sanding process
- Shortest part changeover time, fast retooling
- Fully integrated handling with modular peripherals and high autonomy
Grinding of hardened bar material:
- High-precision parts can be finish-ground directly from hardened bar stock
- Optimal process for the manufacture of unmachined parts with high-precision centres and minimal oversize for subsequent machining operations
