1 spindle honing centre ID 101326

Speed max. 4500 (rpm), stroke drive: ball screw drive, stroke length max. 600 mm

The single-spindle version of this long-stroke honing machine has a compact design. Depending on the machining task and batch size, this machine type can be equipped with either a fixed or rotary indexing table with a maximum of four stations.

Solution for small bore diameters

Small bore diameters often place different demands on the production technology than large ones - a typical problem is the unfavourable length/diameter ratio of the bore. The manufacturer has further developed this series in line with customer requirements and further improved proven assemblies. The result: quality, short delivery times and functionally mature components.

Depending on customer requirements and the range of products to be processed, the machine is equipped with the appropriate honing unit. The honing control enables controlled stroke speeds and switching accuracies.

The bore diameter and taper are determined by a pneumatic air measuring device and shown graphically on the display. Depending on customer requirements, in-process as well as pre- and post-measurement systems can be integrated.

A brushing process can be integrated to remove slight burrs on edges, recesses or cross bores. A centrifugal or blow-off station can also be integrated as an option to remove the coolant from the workpiece.
